Spam is making a bit of a comeback – not that it ever really went away. In fact, spam volumes have been several times higher in the past, but this year it has picked up interest from the security community again, as evidenced, for example, by a paper presented at VB2017 that looked at the technical details of five spam botnets [1], a presentation at AVAR that looked at spam botnets more generally [2], and a presentation at Botconf on perhaps the most well known spam botnet, Necurs [3].
Technically, spam botnets are not the most advanced, and there is a huge gap between them and the sophisticated malware attacks that regularly make the news.
A typical spam bot runs on a machine or device (not just Windows PCs; a lot of spam is sent from compromised web servers or even compromised IoT devices) with very poor security hygiene – it is quite telling that Necurs has not infected any new machines for years.
Spam is also typically sent from countries with relatively high Internet penetration but with relatively low income, which in turn contributes to poor security: more than 25 per cent of the spam messages in this test were sent from machines in either Vietnam or India.
The fact that spam botnets, especially those running on older devices, tend to be relatively easy to detect, contributes to high rates of blocking spam – whether the emails come with a malicious payload or not – although it is worth keeping in mind that the products we test are designed for use in the corporate market, not by home users, and while most ISPs perform a decent amount of spam filtering, it is likely that more bad stuff 'leaks through' to home users.
In this VBSpam test, the 50th of its kind, 14 full solutions were lined up on the Virus Bulletin test bench. No fewer than eight products achieved a VBSpam+ award, while five other products achieved a VBSpam award.
This test once again shows that spam messages with a malicious attachment aren't a big issue for most email security solutions. The fact that almost all of them were blocked by the participating IP blacklists (which block based purely on the sending IP address) shows that it's not just the content of the messages that products act upon: it's the fact that these emails are first and foremost spam and that they are sent from known spam botnets.
That is not to say that, in most cases, the attachments wouldn't have been blocked anyway, but it is worth looking at the attachments themselves to understand that blocking them isn't entirely trivial.
Few would disagree that these attachments are malicious, but all they do – after obfuscation and often some social engineering ('please enable macros to view the hidden content') – is download a piece of malware from a remote server.
This means that a static analysis of the file – as performed by most email security solutions – won't reveal any malicious activity (such as installing a backdoor or encrypting files) and will, at best, reveal similarities with previously seen attachments. Malware authors constantly change the attachments sent in these emails with the explicit intention of evading this kind of detection.
We hope soon to publish a report in which, among other things, we will look more closely at the malware attached to these emails.
Almost all participating vendors have reason to be content with their results in this test, but this is especially the case for OnlyMyEmail, which didn't miss a single spam message among more than 150,000 emails (including thousands carrying malware). It didn't block any legitimate emails either, and with only two false positives in the newsletters corpus, the product is well deserving of a VBSpam+ award.
VBSpam+ awards were also achieved by Bitdefender, CYREN, ESET, Fortinet, IBM, Libra Esva, and both Kaspersky products. For CYREN this is a clear demonstration that the poor results seen in the last test were not representative of the product's general performance.
It was interesting to note that two of the three domain blacklists included in the test, both of which blocked domains in more than 50% of spam emails in the September test, saw a significant drop in their catch rate. This is often a sign of a shift in spammers' techniques towards emails that contain only links to legitimate domains that are used to host the spammy/malicious content, or to redirect to other sites, or emails that contain no links at all.
Finally, it is worth noting once again that all percentages reported here should be seen in the context of the test. In the real world, thanks to a combination of factors, catch rates as perceived by both systems administrators and end-users will be lower for all participating products.
SC rate: 99.76%
FP rate: 0.06%
Final score: 99.42
Project Honey Pot SC rate: 99.48%
Abusix SC rate: 99.97%
Newsletters FP rate: 1.1%
Malware SC rate: 99.98%
| 10% |  |
50% | |
95% | |
98% | |
SC rate: 99.96%
FP rate: 0.00%
Final score: 99.96
Project Honey Pot SC rate: 99.93%
Abusix SC rate: 99.99%
Newsletters FP rate: 0.0%
Malware SC rate: 100.00%
| 10% | |
50% | |
95% | |
98% | |
SC rate: 98.89%
FP rate: 0.00%
Final score: 98.83
Project Honey Pot SC rate: 97.77%
Abusix SC rate: 99.73%
Newsletters FP rate: 1.4%
Malware SC rate: 99.48%
| 10% | |
50% | |
95% | |
98% | |
SC rate: 99.997%
FP rate: 0.00%
Final score: 99.997
Project Honey Pot SC rate: 99.995%
Abusix SC rate: 99.998%
Newsletters FP rate: 0.0%
Malware SC rate: 100.00%
| 10% | |
50% | |
95% | |
98% | |
SC rate: 99.42%
FP rate: 0.10%
Final score: 98.89
Project Honey Pot SC rate: 98.71%
Abusix SC rate: 99.95%
Newsletters FP rate: 0.4%
Malware SC rate: 100.00%
| 10% | |
50% | |
95% | |
98% | |
SC rate: 99.99%
FP rate: 0.00%
Final score: 99.99
Project Honey Pot SC rate: 99.998%
Abusix SC rate: 99.99%
Newsletters FP rate: 0.0%
Malware SC rate: 100.00%
| 10% | |
50% | |
95% | |
98% | |
SC rate: 99.98%
FP rate: 0.00%
Final score: 99.97
Project Honey Pot SC rate: 99.96%
Abusix SC rate: 99.99%
Newsletters FP rate: 0.4%
Malware SC rate: 99.98%
| 10% | |
50% | |
95% | |
98% | |
SC rate: 99.97%
FP rate: 0.00%
Final score: 99.97
Project Honey Pot SC rate: 99.94%
Abusix SC rate: 99.99%
Newsletters FP rate: 0.0%
Malware SC rate: 99.88%
| 10% | |
50% | |
95% | |
98% | |
SC rate: 99.99%
FP rate: 0.00%
Final score: 99.99
Project Honey Pot SC rate: 99.99%
Abusix SC rate: 99.99%
Newsletters FP rate: 0.0%
Malware SC rate: 100.00%
| 10% | |
50% | |
95% | |
98% | |
SC rate: 99.95%
FP rate: 0.00%
Final score: 99.92
Project Honey Pot SC rate: 99.91%
Abusix SC rate: 99.98%
Newsletters FP rate: 0.7%
Malware SC rate: 100.00%
| 10% | |
50% | |
95% | |
98% |  |
SC rate: 100.00%
FP rate: 0.00%
Final score: 99.97
Project Honey Pot SC rate: 100.00%
Abusix SC rate: 100.00%
Newsletters FP rate: 0.7%
Malware SC rate: 100.00%
| 10% | |
50% | |
95% | |
98% | |
SC rate: 99.97%
FP rate: 0.31%
Final score: 98.20
Project Honey Pot SC rate: 99.93%
Abusix SC rate: 99.99%
Newsletters FP rate: 4.9%
Malware SC rate: 99.98%
| 10% | |
50% | |
95% | |
98% | |
SC rate: 99.66%
FP rate: 0.42%
Final score: 97.55
Project Honey Pot SC rate: 99.37%
Abusix SC rate: 99.87%
Newsletters FP rate: 0.7%
Malware SC rate: 99.95%
| 10% | |
50% | |
95% | |
98% | |
SC rate: 99.96%
FP rate: 0.00%
Final score: 99.81
Project Honey Pot SC rate: 99.92%
Abusix SC rate: 99.98%
Newsletters FP rate: 3.5%
Malware SC rate: 100.00%
| 10% | |
50% | |
95% | |
98% | |
SC rate: 95.33%
FP rate: 0.01%
Final score: 95.26
Project Honey Pot SC rate: 95.36%
Abusix SC rate: 95.31%
Newsletters FP rate: 0.0%
Malware SC rate: 97.78%
SC rate: 92.89%
FP rate: 0.01%
Final score: 92.81
Project Honey Pot SC rate: 90.55%
Abusix SC rate: 94.62%
Newsletters FP rate: 0.0%
Malware SC rate: 97.78%
SC rate: 19.98%
FP rate: 0.00%
Final score: 19.98
Project Honey Pot SC rate: 42.92%
Abusix SC rate: 2.93%
Newsletters FP rate: 0.0%
Malware SC rate: 0.13%
SC rate: 12.89%
FP rate: 0.00%
Final score: 12.89
Project Honey Pot SC rate: 26.62%
Abusix SC rate: 2.69%
Newsletters FP rate: 0.0%
Malware SC rate: 0.55%
SC rate: 96.54%
FP rate: 0.00%
Final score: 96.54
Project Honey Pot SC rate: 94.09%
Abusix SC rate: 98.37%
Newsletters FP rate: 0.0%
Malware SC rate: 99.87%
SC rate: 97.44%
FP rate: 0.00%
Final score: 97.44
Project Honey Pot SC rate: 95.52%
Abusix SC rate: 98.86%
Newsletters FP rate: 0.0%
Malware SC rate: 99.87%
SC rate: 12.02%
FP rate: 0.01%
Final score: 11.94
Project Honey Pot SC rate: 25.03%
Abusix SC rate: 2.34%
Newsletters FP rate: 0.0%
Malware SC rate: 0.03%
| True negatives | False positives | FP rate | False negatives | True positives | SC rate | VBSpam | Final score | |
| Axway | 6671 | 4 | 0.06% | 371 | 154316 | 99.76% |  |
99.42 |
| Bitdefender | 6675 | 0 | 0.00% | 55 | 154632 | 99.96% |  |
99.96 |
| CYREN | 6675 | 0 | 0.00% | 1711 | 152976 | 98.89% | |
98.83 |
| ESET | 6675 | 0 | 0.00% | 5 | 154682 | 99.997% | |
99.997 |
| Forcepoint | 6668 | 7 | 0.10% | 894 | 153793 | 99.42% | |
98.89 |
| FortiMail | 6675 | 0 | 0.00% | 10 | 154677 | 99.99% | |
99.99 |
| IBM | 6675 | 0 | 0.00% | 29 | 154658 | 99.98% | |
99.97 |
| Kaspersky for Exchange | 6675 | 0 | 0.00% | 21 | 154666 | 99.99% | |
99.99 |
| Kaspersky LMS | 6675 | 0 | 0.00% | 14 | 154673 | 99.99% | |
99.99 |
| Libra Esva | 6675 | 0 | 0.00% | 74 | 154613 | 99.95% | |
99.92 |
| OnlyMyEmail | 6675 | 0 | 0.00% | 0 | 154687 | 100.00% | |
99.97 |
| Scrollout | 6654 | 21 | 0.31% | 54 | 154633 | 99.97% | |
98.20 |
| Vade Secure Cloud | 6647 | 28 | 0.42% | 533 | 154154 | 99.66% | X | 97.55 |
| ZEROSPAM | 6675 | 0 | 0.00% | 67 | 154620 | 99.96% | |
99.81 |
| IBM X-Force Combined* | 6674 | 1 | 0.01% | 7224 | 147463 | 95.33% | N/A | 95.26 |
| IBM X-Force IP* | 6674 | 1 | 0.01% | 11004 | 143683 | 92.89% | N/A | 92.81 |
| IBM X-Force URL* | 6675 | 0 | 0.00% | 123778 | 30909 | 19.98% | N/A | 19.98 |
| Spamhaus DBL* | 6675 | 0 | 0.00% | 134744 | 19943 | 12.89% | N/A | 12.89 |
| Spamhaus ZEN* | 6675 | 0 | 0.00% | 5345 | 149342 | 96.54% | N/A | 96.54 |
| Spamhaus ZEN+DBL* | 6675 | 0 | 0.00% | 3967 | 150720 | 97.44% | N/A | 97.44 |
| URIBL* | 6674 | 1 | 0.01% | 136100 | 18587 | 12.02% | N/A | 11.94 |
*The IBM X-Force, Spamhaus and URIBL products are partial solutions and their performance should not be compared with that of other products.
(Please refer to the text for full product names and details.)
| Newsletters | Malware | Project Honey Pot | Abusix | STDev† | Speed | ||||||||
| False positives | FP rate | False negatives | SC rate | False negatives | SC rate | False negatives | SC rate | 10% | 50% | 95% | 98% | ||
| Axway | 3 | 1.1% | 1 | 99.98% | 340 | 99.48% | 31 | 99.97% | 0.70 | |
|
|
|
| Bitdefender | 0 | 0.0% | 0 | 100.00% | 48 | 99.93% | 7 | 99.99% | 1.26 | |
|
|
|
| CYREN | 4 | 1.4% | 31 | 99.48% | 1474 | 97.77% | 240 | 99.73% | 3.00 | |
|
|
|
| ESET | 0 | 0.0% | 0 | 100.00% | 3 | 99.995% | 2 | 99.998% | 0.05 | |
|
|
|
| Forcepoint | 1 | 0.4% | 0 | 100.00% | 849 | 98.71% | 45 | 99.95% | 1.26 | |
|
|
|
| FortiMail | 0 | 0.0% | 0 | 100.00% | 1 | 99.998% | 9 | 99.99% | 0.04 | |
|
|
|
| IBM | 1 | 0.4% | 1 | 99.98% | 24 | 99.96% | 5 | 99.99% | 0.12 | |
|
|
|
| Kaspersky for Exchange | 0 | 0.0% | 7 | 99.88% | 8 | 99.99% | 13 | 99.99% | 0.64 | |
|
|
|
| Kaspersky LMS | 0 | 0.0% | 0 | 100.00% | 6 | 99.99% | 8 | 99.99% | 0.09 | |
|
|
|
| Libra Esva | 2 | 0.7% | 0 | 100.00% | 59 | 99.91% | 15 | 99.98% | 0.36 | |
|
|
|
| OnlyMyEmail | 2 | 0.7% | 0 | 100.00% | 0 | 100.00% | 0 | 100.00% | 0.00 | |
|
|
|
| Scrollout | 14 | 4.9% | 1 | 99.98% | 44 | 99.93% | 10 | 99.99% | 0.26 | |
|
|
|
| Vade Secure Cloud | 2 | 0.7% | 3 | 99.95% | 418 | 99.37% | 115 | 99.87% | 0.99 | |
|
|
|
| ZEROSPAM | 10 | 3.5% | 0 | 100.00% | 50 | 99.92% | 17 | 99.98% | 0.31 | |
|
|
|
| IBM X-Force Combined* | 0 | 0.0% | 133 | 97.78% | 3062 | 95.36% | 4162 | 95.31% | 5.51 | N/A | N/A | N/A | N/A |
| IBM X-Force IP* | 0 | 0.0% | 133 | 97.78% | 6231 | 90.55% | 4773 | 94.62% | 7.01 | N/A | N/A | N/A | N/A |
| IBM X-Force URL* | 0 | 0.0% | 5981 | 0.13% | 37654 | 42.92% | 86125 | 2.93% | 19.15 | N/A | N/A | N/A | N/A |
| Spamhaus DBL* | 0 | 0.0% | 5956 | 0.55% | 48407 | 26.62% | 86337 | 2.69% | 12.96 | N/A | N/A | N/A | N/A |
| Spamhaus ZEN* | 0 | 0.0% | 8 | 99.87% | 3896 | 94.09% | 1449 | 98.37% | 4.51 | N/A | N/A | N/A | N/A |
| Spamhaus ZEN+DBL* | 0 | 0.0% | 8 | 99.87% | 2956 | 95.52% | 1011 | 98.86% | 3.64 | N/A | N/A | N/A | N/A |
| URIBL* | 0 | 0.0% | 5987 | 0.03% | 49455 | 25.03% | 86645 | 2.34% | 12.61 | N/A | N/A | N/A | N/A |
* The Spamhaus products, IBM X-Force and URIBL are partial solutions and their performance should not be compared with that of other products. None of the queries to the IP blacklists included any information on the attachments; hence their performance on the malware corpus is added purely for information.
† The standard deviation of a product is calculated using the set of its hourly spam catch rates.
|
0-30 seconds | |
30 seconds to two minutes |  |
two minutes to 10 minutes |  |
more than 10 minutes |
(Please refer to the text for full product names.)
| Hosted solutions | Anti-malware | IPv6 | DKIM | SPF | DMARC | Multiple MX-records | Multiple locations |
| Forcepoint | Forcepoint Advanced Malware Detection | √ | √ | √ | √ | √ | |
| OnlyMyEmail | Proprietary (optional) | √ | √ | * | √ | √ | |
| Vade Secure Cloud | DrWeb; proprietary | √ | √ | √ | √ | √ | |
| ZEROSPAM | ClamAV | √ | √ | √ |
* OnlyMyEmail verifies DMARC status but doesn't provide feedback at the moment.
(Please refer to the text for full product names.)
| Local solutions | Anti-malware | IPv6 | DKIM | SPF | DMARC | Interface | |||
| CLI | GUI | Web GUI | API | ||||||
| Axway MailGate | Kaspersky, McAfee | √ | √ | √ | √ | ||||
| Bitdefender | Bitdefender | √ | √ | √ | √ | ||||
| CYREN | CYREN | √ | √ | √ | |||||
| ESET | ESET Threatsense | √ | √ | √ | √ | √ | √ | ||
| FortiMail | Fortinet | √ | √ | √ | √ | √ | √ | √ | |
| IBM | Sophos; IBM Remote Malware Detection | √ | √ | √ | |||||
| Kaspersky for Exchange | Kaspersky Lab | √ | √ | √ | √ | ||||
| Kaspersky LMS | Kaspersky Lab | √ | √ | √ | √ | √ | |||
| Libra Esva | ClamAV; others optional | √ | √ | √ | √ | ||||
| Scrollout | ClamAV | √ | √ | √ | √ | ||||
(Please refer to the text for full product names.)
| Products ranked by final score | |
| ESET | 99.997 |
| FortiMail | 99.99 |
| Kaspersky LMS | 99.99 |
| Kaspersky for Exchange | 99.99 |
| OnlyMyEmail | 99.97 |
| IBM | 99.97 |
| Bitdefender | 99.96 |
| Libra Esva | 99.92 |
| ZEROSPAM | 99.81 |
| Axway | 99.42 |
| Forcepoint | 98.89 |
| CYREN | 98.83 |
| Scrollout | 98.20 |
| Vade Secure Cloud | 97.55 |
The message throughout the last 50 VBSpam tests has been a fairly positive one: despite the fact that the spam landscape changes constantly (and the product market with it: the 'spam filters' we started testing in 2009 are now sold as 'email security solutions'), the overwhelming majority of spam is blocked by a wide range of solutions. While we continue to be critical when looking at individual product performance, we are happy to be the deliverers of this good news.
The next test report, which is to be published in March 2018, will once again report on all aspects of spam. Those interested in submitting a product are asked to contact [email protected].
[1] https://www.virusbulletin.com/blog/2017/11/vb2017-paper-peering-spam-botnets/.
[2] http://avar.skdlabs.com/index.php/speakers/the-story-of-the-botnets-behind-malicious-spam-campaigns/.
[3] https://botconf2017.sched.com/event/CtHT/malware-penny-stocks-pharma-spam-necurs-delivers.
The full VBSpam test methodology can be found at https://www.virusbulletin.com/testing/vbspam/vbspam-methodology/.
The test ran for 16 days, from 12am on 11 November to 12am on 27 November 2017. The test corpus consisted of 161,649 emails. 154,687 of these were spam, 65,964 of which were provided by Project Honey Pot, with the remaining 88,723 spam emails provided by spamfeed.me, a product from Abusix. There were 6,675 legitimate emails ('ham') and 287 newsletters.
Moreover, 5,989 emails from the spam corpus were found to contain a malicious attachment; though we report separate performance metrics on this corpus, it should be noted that these emails were also counted as part of the spam corpus.
Emails were sent to the products in real time and in parallel. Though products received the email from a fixed IP address, all products had been set up to read the original sender's IP address as well as the EHLO/HELO domain sent during the SMTP transaction, either from the email headers or through an optional XCLIENT SMTP command (http://www.postfix.org/XCLIENT_README.html). Consequently, products were able to filter email in an environment that was very close to one in which they would be deployed in the real world.
For those products running in our lab, we ran them as virtual machines on a VMware ESXi cluster. As different products have different hardware requirements – not to mention those running on their own hardware, or those running in the cloud – there is little point comparing the memory, processing power or hardware the products were provided with; we followed the developers' requirements and note that the amount of email we receive is representative of that received by a small organization.
Although we stress that different customers have different needs and priorities, and thus different preferences when it comes to the ideal ratio of false positives to false negatives, we created a one-dimensional 'final score' to compare products. This is defined as the spam catch (SC) rate minus five times the weighted false positive (WFP) rate. The WFP rate is defined as the false positive rate of the ham and newsletter corpora taken together, with emails from the latter corpus having a weight of 0.2:
WFP rate = (#false positives + 0.2 * min(#newsletter false positives , 0.2 * #newsletters)) / (#ham + 0.2 * #newsletters)
Final score = SC - (5 x WFP)
In addition, for each product, we measure how long it takes to deliver emails from the ham corpus (excluding false positives) and, after ordering these emails by this time, we colour-code the emails at the 10th, 50th, 95th and 98th percentiles:
|
(green) = up to 30 seconds |
|
(yellow) = 30 seconds to two minutes |
|
(orange) = two to ten minutes |
|
(red) = more than ten minutes |
Products earn VBSpam certification if the value of the final score is at least 98 and the 'delivery speed colours' at 10 and 50 per cent are green or yellow and that at 95 per cent is green, yellow or orange.
Meanwhile, products that combine a spam catch rate of 99.5% or higher with a lack of false positives, no more than 2.5% false positives among the newsletters and 'delivery speed colours' of green at 10 and 50 per cent and green or yellow at 95 and 98 per cent earn a VBSpam+ award.
